Stitcher spare part kits

We sale genuine Stitcher replacement parts. Listed below are Ideal spare part kits that are currently available.  Choose the kit that matches your machine crown width and wire size used.  This information is located on the inside cover of your operator manual.  If you are unsure of which part you require please contact Green Notions with your machine model # and serial #, we will assist you with matching which kit matches your machine.

Emergency Maintenance Survival Kits

7/16” Crown .020x.103 Wire

Kit Contains:                                         Standard LH  Head

1-Driver End ( A-301-E2)
2- Driver End Screws (A-422)
1-Anvil (A-305-E2)
1-Anvil Spring (A-359)
4-Cutter Blades (A-304-1/4)
4-Cutter Blade Screws (A-422)		 1-Clutch Spring Pin (A-401)
1-Clutch Pin (A-400)
1-Former Plunger (A-313-E2)
1-Former Plunger Spring (A-314)
1-Former Plunger Screw (A-312)
2-Cutter Tube (A-316-2)
1-Wire Check Complete (AA-336-2)

These Parts can also be used for Acme Silverstitchers, American, Champion, Diagraph Bradley, Heller, Inland, and Young Stitching Machines.

1-1/4” Crown .020x.103 Wire

Kit Contains:                                           Arc Wire

1-Anvil Post (WSA-1080)
1-Anvil Stud (A-3076)
1-Anvil Spring (A-3075)
2-Cutter Blades (110-569)
4- Cutter Blade Screws (202-188)		 1-Support (A-309-U)
1-Clutch Pin Spring (A-401)
1-Clutch Pin (A-400)
2-Cutter Tubes (AA-316-2A)

1-3/8” Crown.037x.074 Flat Wire

Kit Contains:

1-Anvil Post (WSA-1080)
1-Anvil Stud (A-3076)
1-Anvil Spring (A-3075)
2-Cutter Blades (110-103)
4-Cutter Blade Screws (202-188)		 1-Supporter Spring (WSA-1076)
1-Supporter (WSA-8309)
1-Clutch Pin Spring (A-401)
1-Clutch Pin (A-400)
2-Cutter Tubes (WSA-8316)

1-1/4” Crown.028x.103 Wire

Kit Contains:                                  Flat Wire

1-Anvil Post (WSA-1080)
1-Anvil Stud (A-3076)
1-Anvil Spring (A-3075)
2-Cutter Blades (110-69)
4- Cutter Blade Screws (202-188)		 1-Support (A-309-U)
1-Clutch Pin Spring (A-401)
1-Clutch Pin (A-400)
2-Cutter Tubes (AA-316-2A)
